1988-1998 Chevy OBS 1500, 14" Forged Superlite 4 Piston Rear, Wilwood 140-17543
Forged Narrow Superlite 4R Big Brake Rear Parking Brake Kit - 140-17543
Forged Narrow Superlite 4R rear disc kits provide the ultimate Big Brake solution for popular muscle car rear axles that require a parking brake. FNSL4R four piston calipers, 13” or 14” two-piece rotors, and high performance BP-10 compound pads provide optimized and balanced braking to compliment front big brake upgrades on all types of custom, show and high performance street machines. The neatly hidden internal shoe system provides a clean installation with superior static holding power for parking. Optional caliper finishes and rotor designs allow builders to personalize the style and performance for every application.

Kit Summary
Rear End Axle:88-98 C1500
Axle Offset:3.25
Mount Type:Radial
Caliper Type:4 Piston - Powder Coat
Rotor Diameter:14.00


1988-1998 Chevy OBS 1500, 14" Forged Superlite 4 Piston Rear, Wilwood 140-17543

$2,190.00Price
Caliper Color
